Hardware

LAN Interface

Giga x 2

PoE

LAN1: Passive PoE in

LAN2: Passive PoE out

Antenna

Type: Internal / Gain: 14dBi Patch Antenna (5GHz)

SMA Connector x 2 for External Antennas

Power

48V Passive PoE

Dimensions (L x W x H)

27.18 x 12.09 x 3.5 cm

Weight

592g

Power Consumption (Full Loading)

10.6W

Mounting

Pole/Wall

Slide Switch/Reset

LAN2 PSE-OUT Power On/Off, Reset

LED Indicator

Power, LAN1, LAN2, Strength, Signal, RSSI, 5G

Environmental Conditions

Operating Temperature: -20°C (-4°F) to 60°C (140°F)

Operating Humidity: 90% or Less

Power Saving

802.3az

Internal Buzzer

Y

Housing

Outdoor IP55 Weatherproof Rated

Wireless

Standard

802.11 a/an/ac

No. of Radios

1

Receiver Sensitivity

≤ -89Bm

Certification

CE/FCC

Fast Roaming

Y

Number of SSIDs

16 (5GHz)

Performance

Maximum Data Speed

866Mbps

Concurrent Clients

Up to 50 Per Radio

Security

Encryption

WEP / WPA / WPA2

Wireless L2 Isolation

Y

Station Isolation

Y

IEEE 802.1x Authenticator

Y

EAP Authentication

PEAP

Hidden SSID

Y

MAC Address Filter

Y

Wireless STA

Y

Rogue AP Detection (w/ NMS)

Y

Software

Wireless Mode

AP / WDS AP / WDS Bridge / Client

802.1q VLAN

Y (VID = 1-4095)

Spanning Tree

RSTP

QoS

WMM (802.11e)

Max Associated Station No.

Pass-Through

IPv6 and VPN (PPTP, L2TP/IPsec)

DSCP (802.1p)

Y

Multicast Rate up to 54Mbps

Y
